Effective Contaminant Removal with Sock Depth Filters

Sock Depth Filters are used to filter various contaminants from fuels, gasses, amines, lubricating oils and other liquids. The densely packed cotton and/or other organic materials remove hard particles, semi-solids, gums, vanish and acids.

Contact Us

Product Details

Key Features
Advantages
Applications

Key Features

Our unique rolled and layered construction provides improved efficiency and service life. Our patented “Swirl Flow” design has low pressure drop and extraordinary dirt holding capacity. Replacements available for companies such as Jonell, PECO, United Engine Life, and Nelson/Winslow.

Advantages

Cotton’s fine fiber diameter and oliophyllic properties make it an ideal medium for hydrocarbon filtration. We use only natural cotton fibers (not textile waste) in our products.

Wood absorbs water and acids (extending lube oil drain intervals) and improves the filter’s flow characteristics. Our wood is grown and processed here in locally for excellent cost control.



Applications

  • Fuel Filtration
  • Gas Processing
  • Large Engine
  • Large Compressor
  • Lubricating Oil
  • Rotating Equipment
  • Acid Removal
  • Gas Processing Solvents
  • Amine
  • Diesel Fuel Filtration
  • Hydrocarbon Filtration

Cross Reference

Jonell Part NumberSCIS Part NumberDimensions
JB-1031-C-H1031-C-1-102.5″ Dia. x 10″ Long
JB-1031-C-H-21031-C-2-102.5″ Dia. x 20″ Long
JB-1031-C-H-31031-C-3-102.5″ Dia. x 30″ Long
JB-1031-C-KM1031-C-1-252.5″ Dia. x 10″ Long
JB-1031-C-KM-21031-C-2-252.5″ Dia. x 20″ Long
JB-1031-C-KM-31031-C-3-252.5″ Dia. x 30″ Long
JB-1031-O-H1031-O-1-102.5″ Dia. x 10″ Long
JB-1031-O-H-21031-O-2-102.5″ Dia. x 20″ Long
JB-1031-O-H-31031-O-3-102.5″ Dia. x 30″ Long
JB-1031-O-KM1031-O-1-252.5″ Dia. x 10″ Long
JB-1031-O-KM-21031-O-2-252.5″ Dia. x 20″ Long
JB-1031-O-KM-31031-O-3-252.5″ Dia. x 30″ Long
JB-1044-O-KM1044-O-GD4.1″ Dia. x 9.8″ Long
JB-113-C-HME-113-H5.0″ Dia. x 19.3″ Long
JB-1251-O-KM1251-O4.8″ Dia. x 12.0″ Long
JB-139-FME-139-F5.0″ Dia. x 29.0″ Long
JB-139-FXME-139-FX5.0″ Dia. x 29.0″ Long
JB-1542-O-KM1542-T3.8″ Dia. x 15.8″ Long
JB-1555-4L-C-KM1555-4L6.5″ Dia. x 30.5″ Long
JB-1645-C-KM1645-C-154.3″ Dia. x 16.0″ Long
JB-1645-O-H1645-GD4.3″ Dia. x 16.0″ Long
JB-1645-O-KM1656-O4.5″ Dia. x 16.0″ Long
JB-1865-C-KM758-1336.5″ Dia. x 18.5″ Long
JB-1874-0-H1874-GD6.5″ Dia. x 17.3″ Long
JB-1874-0-KM1874-T6.5″ Dia. x 17.3″ Long
JB-2278-C-H2278-C-1-102.5″ Dia. x 9.8″ Long
JB-2278-C-H-22278-C-2-102.5″ Dia. x 19.5″ Long
JB-2278-C-H-32278-C-3-102.5″ Dia. x 29.25″ Long
JB-2278-C-KM2278-C-1-252.5″ Dia. x 9.8″ Long
JB-2278-C-KM-22278-C-2-252.5″ Dia. x 19.5″ Long
JB-2278-C-KM-32278-C-3-252.5″ Dia. x 29.25″ Long
JB-2278-O-H2278-O-1-102.5″ Dia. x 9.8″ Long
JB-2278-O-H-22278-O-2-102.5″ Dia. x 19.5″ Long
JB-2278-O-H-32278-O-3-102.5″ Dia. x 29.25″ Long
JB-2278-O-KM2278-O-1-252.5″ Dia. x 9.8″ Long
JB-2278-O-KM-22278-O-2-252.5″ Dia. x 19.5″ Long
JB-2278-O-KM-32278-O-3-252.5″ Dia. x 29.25″ Long
JB-2728-C-H2727-EC2.7″ Dia. x 27.0″ Long
JB-2728-C-KM2727-T2.7″ Dia. x 27.0″ Long
JB-3042-O-KM3042-O-254.0″ Dia. x 31.0″ Long
JB-3107-C-H740-C-53.0″ Dia. x 7.3″ Long
JB-3107-KM740-C-253.0″ Dia. x 7.3″ Long
JB-318-C-10318-C-103.0″ Dia. x 18.3″ Long
JB-318-C-10-P318-C-10-P3.0″ Dia. x 18.3″ Long
JB-318-C-25318-C-253.0″ Dia. x 18.3″ Long
JB-318-C-25-P318-C-25-P3.0″ Dia. x 18.3″ Long
JB-318-C-5318-C-53.0″ Dia. x 18.3″ Long
JB-318-C-50318-C-503.0″ Dia. x 18.3″ Long
JB-318-C-5-P318-C-5-P3.0″ Dia. x 18.3″ Long
JB-318-C-AC318-C-AC3.0″ Dia. x 18.3″ Long
JB-318-O-10318-O-103.0″ Dia. x 18.3″ Long
JB-318-O-25318-O-253.0″ Dia. x 18.3″ Long
JB-318-O-5318-O-53.0″ Dia. x 18.3″ Long
JB-318-O-50318-O-503.0″ Dia. x 18.3″ Long
JB-322-C-5322-C-53.0″ Dia. x 22.0″ Long
JB-3245-O-H3256-O4.5″ Dia. x 32.0″ Long
JB-3245-O-KM3245-T4.3″ Dia. x 32.0″ Long
JB-330-C-10330-C-103.0″ Dia. x 30.6″ Long
JB-330-C-5330-C-53.0″ Dia. x 30.6″ Long
JB-336-C-10336-C-103.0″ Dia. x 36.6″ Long
JB-336-C-100336-C-1003.0″ Dia. x 36.6″ Long
JB-336-C-10-P336-C-10-P3.0″ Dia. x 36.6″ Long
JB-336-C-25336-C-253.0″ Dia. x 36.6″ Long
JB-336-C-25-P336-C-25-P3.0″ Dia. x 36.6″ Long
JB-336-C-5336-C-53.0″ Dia. x 36.6″ Long
JB-336-C-50336-C-503.0″ Dia. x 36.6″ Long
JB-336-C-50-P336-C-50-P3.0″ Dia. x 36.6″ Long
JB-336-C-5-P336-C-5-P3.0″ Dia. x 36.6″ Long
JB-336-C-75336-C-753.0″ Dia. x 36.6″ Long
JB-336-C-AC336-C-AC3.0″ Dia. x 36.6″ Long
JB-336-O-10336-O-103.0″ Dia. x 36.6″ Long
JB-336-O-25336-O-253.0″ Dia. x 36.6″ Long
JB-336-O-5336-O-53.0″ Dia. x 36.6″ Long
JB-336-O-50336-O-503.0″ Dia. x 36.6″ Long
JB-3508-O-KM842-O3.5″ Dia. x 8.0″ Long
JB-36B-C-KMERCE-36-B3.0″ Dia. x 36.0″ Long
JB-436-C-10436-C-104.0″ Dia x 36.6″ Long
JB-436-C-2436-C-24.0″ Dia x 36.6″ Long
JB-436-C-25436-C-254.0″ Dia x 36.6″ Long
JB-436-C-25436-C-254.0″ Dia x 36.6″ Long
JB-436-C-8436-C-84.0″ Dia x 36.6″ Long
JB-436-O-2436-O-24.0″ Dia x 36.6″ Long
JB-436-O-5436-O-54.0″ Dia x 36.6″ Long
JB-436-O-8436-O-84.0″ Dia x 36.6″ Long
JB-518-C-H518-B4.9″ Dia. x 18.1″ Long
JB-627-C-KM627-C-255.8″ Dia. x 27.0″ Long
JB-631-O-KM631-O6.4″ Dia x 31.3″ Long
JB-718-C-H7518-B6.8″ Dia. x 18.1″ Long
JB-718-C-KM7518-S6.8″ Dia. x 18.1″ Long
JB-7518-O-H7518-O-106.8″ Dia. x 18.1″ Long
JB-7518-O-KM7518-O-256.8″ Dia. x 18.1″ Long
JB-7518-O-M718-C-256.5″ Dia. x 18.0″ Long
JB-7536-C-H75366.8″ Dia. x 36.0″ Long
JB-757-315-E757-3156.5″ Dia. x 18.5″ Long
JB-ERD-10-DERD-10-D5.3″ Dia. x 9.8″ Long
JB-ERD-12-DERD-12-D4.0″ Dia. x 12.3″ Long
JB-ERD-24-DERD-24-D5.3″ Dia. x 27.3″ Long
JB-ERD-36-DERD-36-D5.3″ Dia. x 36.0″ Long
JBP-30-O-H722-B7.0″ Dia. x 22.0″ Long
JCS-631-0-KM3265-CEA6.5″ Dia. x 32.0″ Long
JEL-518EL-518-B4.9″ Dia. x 18.1″ Long
JN-1280-1R1280-1R4.5″ Dia. x 9.6″ Long
JNM-1645-T1645-O-54.3″ Dia. x 16.0″ Long
JNW-1541-T1541-C-253.8″ Dia. x 15.8″ Long
JNW-1542-2T1542-2T3.8″ Dia. x 31.8″ Long
JNW-1542-T1542-T3.8″ Dia. x 15.8″ Long
JNW-1544-T1544-T3.8″ Dia. x 15.8″ Long
JNW-1645-2-C3245-T4.3″ Dia. x 32.0″ Long
JNW-1656-O-21656-O-24.5″ Dia. x 32.0″ Long
JNW-2278-10-22278-C-2-102.5″ Dia. x 19.5″ Long
JNW-2278-10-32278-C-3-102.5″ Dia. x 29.25″ Long
JNW-2278-25-22278-C-2-252.5″ Dia. x 19.5″ Long
JNW-2278-25-32278-C-3-252.5″ Dia. x 29.25″ Long
JNW-2278-50-22278-C-2-502.5″ Dia. x 19.5″ Long
JNW-2278-50-32278-C-3-502.5″ Dia. x 29.25″ Long
JNW-2278-5-22278-C-2-52.5″ Dia. x 19.5″ Long
JNW-2278-5-32278-C-3-52.5″ Dia. x 29.25″ Long
JP-20-S1031-C-2-502.5″ Dia. x 20″ Long
JWC-318-C-10318-C-103.0″ Dia. x 18.3″ Long
JWC-318-C-25318-C-253.0″ Dia. x 18.3″ Long
JWC-318-C-5318-C-53.0″ Dia. x 18.3″ Long
JWC-318-C-75318-C-753.0″ Dia. x 18.3″ Long
JWC-336-C-10336-C-103.0″ Dia. x 36.6″ Long
JWC-336-C-25336-C-253.0″ Dia. x 36.6″ Long
JWC-336-C-5336-C-53.0″ Dia. x 36.6″ Long
JWC-436-C-2436-C-24.0″ Dia x 36.6″ Long
JWC-436-C-25436-C-254.0″ Dia x 36.6″ Long
JWC-436-O-2436-O-24.0″ Dia x 36.6″ Long
JWC-436-O-25436-O-254.0″ Dia x 36.6″ Long
JWC-436-O-50436-O-504.0″ Dia x 36.6″ Long
JWC-5218-0-KM517-CEA5.0″ Dia. x 17.1″ Long
JWC-7518-C-H7518-C-106.8″ Dia. x 18.1″ Long
JWC 330-C-5-NS 330-C-53.0″ Dia x 30.75″ Long
JWC 330-C-5330-C-53.0″ Dia. x 30.75″ Long

Need Reliable Filtration? Get a Quote on Sock Depth Filters

Ensure optimal performance and longevity for your equipment. Request a quote today for our high-efficiency sock depth filters, designed to remove contaminants from fuels, gases, and lubricating oils.
